SU5000 Series Digital Pattern Generator Features
* Direct Digital Synthesis Technology
* Crystal Oscillation Reference
* High Accurate Time and Frequency
* Count burst or single burst both can be selected
* Multiple output channels and EXT
* Trigger/Frequency Standard Input channels
* Data Storage and Recall
* Optional GPIB and USB interface
SU5000 Series Digital Pattern Generator Specifiations
| SU5101/5102 | SU5202G | SU5302 | SU5303 | |
| Channel | 1/2 | 2 | 2 | 1 |
| Waveform | ||||
| Pulse | Single/Dobule, Logic Positive /Negative, Positive/Negative Polary | Single/Dobule, Logic Positive /Negative | Logic Positive /Negative | |
| Edge Time | ≤10ns | ≤10ns | 8ns ~ 1ms | 8ns ~ 1ms |
| Overshoot | ≤ 10% | ≤ 10% | ≤ 10% | ≤ 5% |
| Time | ||||
| Pulse Period | 20ns ~ 10000s (frequency range: 0.1mHz ~ 50MHz) | |||
| Time Interval | 5ns ~ 10000s | 8ns ~ 9999.5s | ||
| Resolution | 5ns (Low range), 10μs (High range) | 0.1ns(typical) | ||
| Interval Error |
± (T×5×10-5 + 5ns)(Low range), ±(T×5×10-5 + 10μs) (High range) |
±(T×5×10-5+5ns) | ||
|
Pattern |
N/A | Length:4095bits | Length:16384bits | |
| Format:NRZ | Format:NRZ, RZ | |||
| Rate:100mHz ~ 50MHz | Rate:2mHz ~ 50MHz | |||
| Resolution: 0.1Hz | ||||
| Amplitude Offset | ||||
| Amplitude Range |
50mV ~ 10V (High Z) |
50mV ~ 5V (50Ω) | 50mV ~ 5V (50Ω) | 50mV ~ 5V (50Ω) |
| Offset Range |
50mV ~ 10V (High Z) |
50mV ~ 5V (50Ω) | 50mV ~ 5V (50Ω) | -5V~ 5V (50Ω) |
| Output Impedance | 50Ω | |||
| TTL | ||||
| TTL/COMS Level | Low Level≤ 0.3V, High Level≥3.0V (high impedance load) | |||
| Output Impedance | 50Ω | |||
| Burst | ||||
| Burst Count | 2 ~ 65000 cycles | |||
| Burst Mode | Continuous, Signle | |||
| EXT. STD Input | ||||
| Frequency | 10M mutiple | |||
| Amplitude | 0.5-5Vpp, AC coupling | |||
| Trigger | ||||
| Trigger Mode | Internal, External, Manual | |||
| Ext. Trigger Input | Frequency: 1Hz ~ 10MHz (Square), Amplitude: 1Vpp ~ 20 Vpp | |||
| Input Impedance | ≥100kΩ | |||
| General Characteristics | ||||
| Power | AC110-240V, 50/60Hz,<80VA | |||
| Display | VFD | 5.7′ TFT LCD | 5.7′ TFT LCD | 4.3′ TFT LCD |
| Optional Interface | USB, GPIB | RS232(Standard),GPIB |
RS-232 (Standard) |
RS232(Standard),GPIB |
| Dimension & Weight |
254×103×384mm, Approx.3 kg |
330×155×300mm,Approx.4.2kg |
450×100×475mm, Approx.6.0 kg |
|
| Технические характеристики | |
| Amplitude Range: 50mV ~ 10V (High Z) | 50mV ~ 5V (50Ω) |
| Channel: 1/2 | 1 |
| Dimension & Weight: 254×103×384mm, Approx.3 kg | 450×100×475mm, Approx.6.0 kg |
| Display: VFD | 4.3′ TFT LCD |
| Edge Time: ≤10ns | 8ns ~ 1ms |
| Interval Error: ± (T×5×10-5 + 5ns)(Low range), ±(T×5×10-5 + 10μs | ±(T×5×10-5+5ns) |
| Offset Range: 50mV ~ 10V (High Z) | -5V~ 5V (50Ω) |
| Offset Range: Amplitude | 0.5-5Vpp, AC coupling |
| Offset Range: Burst Count | 2 ~ 65000 cycles |
| Offset Range: Burst Mode | Continuous, Signle |
| Offset Range: Ext. Trigger Input | Frequency: 1Hz ~ 10MHz (Square), Amplitude: 1Vpp ~ 20 Vpp |
| Offset Range: Frequency | 10M mutiple |
| Offset Range: Input Impedance | ≥100kΩ |
| Offset Range: Output Impedance | 50Ω |
| Offset Range: Power | AC110-240V, 50/60Hz,<80VA |
| Offset Range: TTL/COMS Level | Low Level≤ 0.3V, High Level≥3.0V (high impedance load) |
| Offset Range: Trigger Mode | Internal, External, Manual |
| Optional Interface: USB, GPIB | RS232(Standard),GPIB |
| Overshoot: Pulse Period | 20ns ~ 10000s (frequency range: 0.1mHz ~ 50MHz) |
| Overshoot: ≤ 10% | ≤ 5% |
| Pattern: Format:NRZ | Format:NRZ, RZ |
| Pattern: N/A | Length:16384bits |
| Pattern: Rate:100mHz ~ 50MHz | Rate:2mHz ~ 50MHz |
| Pulse: Single/Dobule, Logic Positive /Negative, Positive/Negativ | Logic Positive /Negative |
| Resolution: 5ns (Low range), 10μs (High range) | 0.1ns(typical) |
| SU5101/5102: SU5202G | SU5303 |
| Time Interval: 5ns ~ 10000s | 8ns ~ 9999.5s |
